CRYOCHILL™ cryovial, Star-Foot, Sterile
CRYOCHILL™ cryovial, Star-Foot, Sterile - Image 2

CRYOCHILL™ cryovial Star-Foot Sterile, CRYOCHILL™ Labware

CRYOCHILL™ cryovial, Star-Foot, Sterile

Star-Foot CRYOCHILL™ cryovials are available with both external and internal threaded designs. These vials are made from USP Class VI compliant polypropylene (PP), while the threaded closures are manufactured from high-density polyethylene (HDPE) and feature 0.1 mL graduation markings. The internally threaded caps include a silicone washer for better sealing efficiency. Designed for durability, the vials provide reliable protection under extreme temperature conditions and are suitable for use in the vapor phase of liquid nitrogen as well as in mechanical freezers. They comply with IATA standards, with the ability to withstand evacuation to 95 kPa without leakage, making them suitable for transporting diagnostic specimens. Produced in an ISO Class 8 cleanroom, CRYOCHILL™ Star-Foot vials are certified free from detectable DNase, RNase, and pyrogens.

Warning: Do not use cryovials or storage boxes in liquid phase of liquid Nitrogen as it may cause entrapment of liquefied Nitrogen inside the vial which leads to pressure build up, resulting in possible explosion of biohazard release. Always use appropriate safety equipment when removing cryovials from cryogenic storage.

Certificates..
Catalog No. Technical Data Thread Style Capacity (mL) Brim Volume (mL) Ø x h (mm) Inner Bottom Type Sterility Autoclavability Packaging Details
523011

External 1.0 1.8 12 x 35 Star-Foot with Round bottom Yes No PK 1000
  523011
Description: 1.0 mL CRYOCHILLTM Vial, Ext. Threaded, Star-Foot, PP, Gamma Sterile
Product Type: CRYOCHILLTM Vial External Threaded, Star-Foot
Product Material: Polypropylene (PP) / High-Density Polyethylene (HDPE)
Colour: Clear (Natural)
External Neck Diameter: 11.3 mm
Internal Neck Diameter: 9.8 mm
Outer Body Diameter: 12.0 mm
Avg Wall Thickness: 1.20 mm
Height without Cap: 28.7 mm
Height with Cap: 35.0 mm
Closure Outer Diameter: 13.8 mm
Tube Weight: 0.96 g
Closure Weight: 0.57 g
Product Unit Weight: 1.53 g
Graduation Range: 0.5 mL – 1.0 mL
Graduation Interval: 0.1 mL
Brim Volume: 1.8 mL
Thread Type: External
Sterilization: Gamma Sterilized
Leak Test: Leak Proof
Temperature Range: -196°C to 121°C
Packing: 1000 / Bag
Compliance: Manufactured inside Class 8 cleanroom in compliance with ISO 9001 / 13485: 2016 quality requirements. Tubes meet the requirements of FDA-21 CFR, USP Class VI. Free of detectable DNase, RNase, PCR and Pyrogen.
523021

External 1.8 2.6 12 x 47 Star-Foot with Round bottom Yes No PK 1000
  523021
Description: 1.8 mL CRYOCHILLTM Vial, Ext. Threaded, Star-Foot, PP, Gamma Sterile
Product Type: CRYOCHILLTM Vial External Threaded, Star-Foot
Product Material: Polypropylene (PP) / High-Density Polyethylene (HDPE)
Colour: Clear (Natural)
External Neck Diameter: 11.3 mm
Internal Neck Diameter: 9.8 mm
Outer Body Diameter: 12.0 mm
Avg Wall Thickness: 1.20 mm
Height without Cap: 40.6 mm
Height with Cap: 46.9 mm
Closure Outer Diameter: 13.8 mm
Tube Weight: 1.41 g
Closure Weight: 0.57 g
Product Unit Weight: 1.98 g
Graduation Range: 0.5 mL – 1.8 mL
Graduation Interval: 0.1 mL
Brim Volume: 2.6 mL
Thread Type: External
Sterilization: Gamma Sterilized
Leak Test: Leak Proof
Temperature Range: -196°C to 121°C
Packing: 1000 / Bag
Compliance: Manufactured inside Class 8 cleanroom in compliance with ISO 9001 / 13485: 2016 quality requirements. Tubes meet the requirements of FDA-21 CFR, USP Class VI. Free of detectable DNase, RNase, PCR and Pyrogen.
523314

External 3.0 4.2 12 x 70 Star-Foot with Round bottom Yes No PK 500
  523314
Description: 3.0 mL CRYOCHILLTM Vial, Ext. Threaded, Star-Foot, PP, Gamma Sterile
Product Type: CRYOCHILLTM Vial External Threaded, Star-Foot
Product Material: Polypropylene (PP) / High-Density Polyethylene (HDPE)
Colour: Clear (Natural)
External Neck Diameter: 11.3 mm
Internal Neck Diameter: 9.8 mm
Outer Body Diameter: 12.0 mm
Avg Wall Thickness: 1.15 mm
Height without Cap: 63.5 mm
Height with Cap: 69.6 mm
Closure Outer Diameter: 13.8 mm
Tube Weight: 2.22 g
Closure Weight: 0.57 g
Product Unit Weight: 2.79 g
Graduation Range: 0.5 mL – 3.0 mL
Graduation Interval: 0.1 mL
Brim Volume: 4.2 mL
Thread Type: External
Sterilization: Gamma Sterilized
Leak Test: Leak Proof
Temperature Range: -196°C to 121°C
Packing: 500 / Bag
Compliance: Manufactured inside Class 8 cleanroom in compliance with ISO 9001 / 13485: 2016 quality requirements. Tubes meet the requirements of FDA-21 CFR, USP Class VI. Free of detectable DNase, RNase, PCR and Pyrogen.
523315

External 3.5 4.5 12 x 74 Star-Foot with Round bottom Yes No PK 500
  523315
Description: 3.5 mL CRYOCHILLTM Vial, Ext. Threaded, Star-Foot, PP, Gamma Sterile
Product Type: CRYOCHILLTM Vial External Threaded, Star-Foot
Product Material: Polypropylene (PP) / High-Density Polyethylene (HDPE)
Colour: Clear (Natural)
External Neck Diameter: 11.3 mm
Internal Neck Diameter: 9.8 mm
Outer Body Diameter: 12.1 mm
Avg Wall Thickness: 1.16 mm
Height without Cap: 68.15 mm
Height with Cap: 74.1 mm
Closure Outer Diameter: 13.8 mm
Tube Weight: 2.40 g
Closure Weight: 0.57 g
Product Unit Weight: 2.97 g
Graduation Range: 0.5 mL – 3.5 mL
Graduation Interval: 0.1 mL
Brim Volume: 4.5 mL
Thread Type: External
Sterilization: Gamma Sterilized
Leak Test: Leak Proof
Temperature Range: -196°C to 121°C
Packing: 500 / Bag
Compliance: Manufactured inside Class 8 cleanroom in compliance with ISO 9001 / 13485: 2016 quality requirements. Tubes meet the requirements of FDA-21 CFR, USP Class VI. Free of detectable DNase, RNase, PCR and Pyrogen.
523031

External 4.5 5.5 12 x 90 Star-Foot with Round bottom Yes No PK 500
  523031
Description: 4.5 mL CRYOCHILLTM Vial, Ext. Threaded, Star-Foot, PP, Gamma Sterile
Product Type: CRYOCHILLTM Vial External Threaded, Star-Foot
Product Material: Polypropylene (PP) / High-Density Polyethylene (HDPE)
Colour: Clear (Natural)
External Neck Diameter: 11.3 mm
Internal Neck Diameter: 9.8 mm
Outer Body Diameter: 12.0 mm
Avg Wall Thickness: 1.20 mm
Height without Cap: 83.6 mm
Height with Cap: 89.9 mm
Closure Outer Diameter: 13.8 mm
Tube Weight: 2.81 g
Closure Weight: 0.57 g
Product Unit Weight: 3.38 g
Graduation Range: 0.5 mL – 4.5 mL
Graduation Interval: 0.1 mL
Brim Volume: 5.5 mL
Thread Type: External
Sterilization: Gamma Sterilized
Leak Test: Leak Proof
Temperature Range: -196°C to 121°C
Packing: 500 / Bag
Compliance: Manufactured inside Class 8 cleanroom in compliance with ISO 9001 / 13485: 2016 quality requirements. Tubes meet the requirements of FDA-21 CFR, USP Class VI. Free of detectable DNase, RNase, PCR and Pyrogen.
523192

Internal 1.0 1.2 12.5 x 42 Star-Foot with V-shaped bottom Yes No PK 1000
  523192
Description: 1.0 mL CRYOCHILLTM Vial, Int. Threaded, Star-Foot, PP, Gamma Sterile
Product Type: CRYOCHILLTM Vial Internal Threaded, Star-Foot
Product Material: Polypropylene (PP) / High-Density Polyethylene (HDPE)
Colour: Clear (Natural)
External Neck Diameter: NA
Internal Neck Diameter: 10.4 mm
Outer Body Diameter: 12.4 mm
Avg Wall Thickness: 1.20 mm
Height without Cap: 32.0 mm
Height with Cap: 41.5 mm
Closure Outer Diameter: 12.2 mm
Tube Weight: 1.16 g
Closure Weight: 0.65 g
Product Unit Weight: 1.81 g
Graduation Range: 0.5 mL – 1.0 mL
Graduation Interval: 0.1 mL
Brim Volume: 1.2 mL
Thread Type: Internal
Sterilization: Gamma Sterilized
Leak Test: Leak Proof
Temperature Range: -196°C to 121°C
Packing: 1000 / Bag
Compliance: Manufactured inside Class 8 cleanroom in compliance with ISO 9001 / 13485: 2016 quality requirements. Tubes meet the requirements of FDA-21 CFR, USP Class VI. Free of detectable DNase, RNase, PCR and Pyrogen.
523193

Internal 1.8 2.2 12.5 x 48 Star-Foot with Round bottom Yes No PK 1000
  523193
Description: 1.8 mL CRYOCHILLTM Vial, Int. Threaded, Star-Foot, PP, Gamma Sterile
Product Type: CRYOCHILLTM Vial Internal Threaded, Star-Foot
Product Material: Polypropylene (PP) / High-Density Polyethylene (HDPE)
Colour: Clear (Natural)
External Neck Diameter: NA
Internal Neck Diameter: 10.4 mm
Outer Body Diameter: 12.4 mm
Avg Wall Thickness: 1.05 mm
Height without Cap: 38.2 mm
Height with Cap: 47.8 mm
Closure Outer Diameter: 12.2 mm
Tube Weight: 1.23 g
Closure Weight: 0.65 g
Product Unit Weight: 1.88 g
Graduation Range: 0.5 mL – 1.0 mL
Graduation Interval: 0.1 mL
Brim Volume: 2.2 mL
Thread Type: Internal
Sterilization: Gamma Sterilized
Leak Test: Leak Proof
Temperature Range: -196°C to 121°C
Packing: 1000 / Bag
Compliance: Manufactured inside Class 8 cleanroom in compliance with ISO 9001 / 13485: 2016 quality requirements. Tubes meet the requirements of FDA-21 CFR, USP Class VI. Free of detectable DNase, RNase, PCR and Pyrogen.
523316

Internal 3.5 5.0 12.5 x 78 Star-Foot with Round bottom Yes No PK 500
  523316
Description: 3.5 mL CRYOCHILLTM Vial, Int. Threaded, Star-Foot, PP, Gamma Sterile
Product Type: CRYOCHILLTM Vial Internal Threaded, Star-Foot
Product Material: Polypropylene (PP) / High-Density Polyethylene (HDPE)
Colour: Clear (Natural)
External Neck Diameter: NA
Internal Neck Diameter: 10.4 mm
Outer Body Diameter: 12.4 mm
Avg Wall Thickness: 0.93 mm
Height without Cap: 67.5 mm
Height with Cap: 77.0 mm
Closure Outer Diameter: 12.2 mm
Tube Weight: 2.18 g
Closure Weight: 0.65 g
Product Unit Weight: 2.83 g
Graduation Range: 0.5 mL – 3.5 mL
Graduation Interval: 0.1 mL
Brim Volume: 5.0 mL
Thread Type: Internal
Sterilization: Gamma Sterilized
Leak Test: Leak Proof
Temperature Range: -196°C to 121°C
Packing: 500 / Bag
Compliance: Manufactured inside Class 8 cleanroom in compliance with ISO 9001 / 13485: 2016 quality requirements. Tubes meet the requirements of FDA-21 CFR, USP Class VI. Free of detectable DNase, RNase, PCR and Pyrogen.
523194

Internal 4.5 5.5 12.5 x 90 Star-Foot with Round bottom Yes No PK 500
  523194
Description: 4.5 mL CRYOCHILLTM Vial, Int. Threaded, Star-Foot, PP, Gamma Sterile
Product Type: CRYOCHILLTM Vial Internal Threaded, Star-Foot
Product Material: Polypropylene (PP) / High-Density Polyethylene (HDPE)
Colour: Clear (Natural)
External Neck Diameter: NA
Internal Neck Diameter: 10.4 mm
Outer Body Diameter: 12.4 mm
Avg Wall Thickness: 1.15 mm
Height without Cap: 81.0 mm
Height with Cap: 90.3 mm
Closure Outer Diameter: 12.2 mm
Tube Weight: 2.75 g
Closure Weight: 0.65 g
Product Unit Weight: 3.4 g
Graduation Range: 0.5 mL – 4.5 mL
Graduation Interval: 0.1 mL
Brim Volume: 5.5 mL
Thread Type: Internal
Sterilization: Gamma Sterilized
Leak Test: Leak Proof
Temperature Range: -196°C to 121°C
Packing: 500 / Bag
Compliance: Manufactured inside Class 8 cleanroom in compliance with ISO 9001 / 13485: 2016 quality requirements. Tubes meet the requirements of FDA-21 CFR, USP Class VI. Free of detectable DNase, RNase, PCR and Pyrogen.

Key Features:

  • Material conforming to USP Class VI.
  • Star Foot.
  • Available with Internal & External threaded closure.
  • Gamma Sterilized.
  • Meet IATA requirements of withstanding evacuation to 95k Pascal without leaking.
  • Suitable for transport of diagnostic specimen.
  • Manufactured in ISO Class 8 cleanroom.
  • Free from detectable DNase, RNase & pyrogen.

Description

Key Features:

  • Material conforming to USP Class VI.
  • Star Foot.
  • Available with Internal & External threaded closure.
  • Gamma Sterilized.
  • Meet IATA requirements of withstanding evacuation to 95k Pascal without leaking.
  • Suitable for transport of diagnostic specimen.
  • Manufactured in ISO Class 8 cleanroom.
  • Free from detectable DNase, RNase & pyrogen.
